Adam Technolgoy, Since 1987
9 Years
| Ask Lasest Price | |
| Brand Name : | AdamPower |
| Model Number : | 8HS2402 |
| Certification : | ISO,CE,ROHS,CCC |
| Price : | 10-20USD/PC |
| Payment Terms : | T/T, Western Union, MoneyGram, L/C |
| Supply Ability : | 100000PCS |
| Delivery Time : | 2-7 Days |
Electrical Specifications:
Series Mode | Step Angleº | Motor Length | Rated voltage (v) | Rated Current (A) | Phase Resistance (Ω) | Phase Indutance (Mh) | Holding Torque(MIN) N.cm | Detent Toruue(MAX) N.cm | Rotor Torque (g.cm2) | Lead Wire | Motor Weight g) |
| 8HS2402 | 1.8 | 28 | 4.6 | 0.2 | 23 | 8.2 | 1.4 | 0.2 | 2.5 | 4 | 50 |
| 8HS2406 | 1.8 | 28 | 1.92 | 0.6 | 3.2 | 0.9 | 1.4 | 0.2 | 2.5 | 4 | 50 |
| 8HS3402 | 1.8 | 33 | 5 | 0.2 | 25 | 8.4 | 1.8 | 0.3 | 3.2 | 4 | 70 |
| 8HS3406 | 1.8 | 33 | 3.9 | 0.6 | 6.5 | 1.7 | 1.8 | 0.3 | 2 | 4 | 60 |
| 8HS4406 | 1.8 | 40 | 3.48 | 0.6 | 5.8 | 1.6 | 2.6 | 0.5 | 4.5 | 4 | 82 |
| 8HS4408 | 1.8 | 40 | 4.32 | 0.8 | 5.4 | 1.5 | 3 | 0.5 | 3.6 | 4 | 80 |
Mechanical Dimensions and Wiring Diagram:
Double Shaft Type stepper motor for CLOSED loop working.
Shaft Mode can be customized as the requirement.
Lead Wire Mode Options:
Note: The Stepping Motors Can be integrated with driver or controller as above.
|
|
